Light Pipe — LED Mounts and Lens Caps

Industrial Fiber Optics offers a wide selection of options in its inexpensive flexible light pipe product line.

Our mounts and lens caps are suitable for:

Surface mount and leaded LEDs
Horizontal and vertical mounts for leaded LEDs
Multi-colored LEDs
Multiple diameters of light pipe
(plastic optical fiber)

Product line features include:

Small size
RoHS-compliant
94V-2 UL Flame Classification
Injection molded for low cost
Off the shelf
No minimum order requirements

* Light pipe mounts are not recommended for data communications applications because the junctions of LED and mounts are not sealed from ambient light.

LED Mounts	Description Part Number Application/Fiber Cable OD	Price (/PKG 500)
	Mount, Vertical, T1 51 0420 3mm (T1) LEDs w/ 2.2mm OD light pipe	$101.25
	Mount, Vertical, T1 51 0421 3mm (T1) LEDs w/ 3mm OD light pipes	$101.25
	Mount, Vertical, T1-3/4 51 0422 5mm (T1-3/4) LEDs w/ 2.2mm OD light pipes	$185.63
	Mount, Vertical, T1-3/4 51 0423 5mm (T1-3/4) LEDs w/ 3mm OD light pipes	$185.63
	Mount, Horizontal, T1 51 0430 3mm (T1) 2-leaded LEDs w/ 2.2mm OD light pipe	$101.25
	Mount, Horizontal, T1 51 0431 3mm (T1) 2-leaded LEDs w/ 3.0mm OD light pipe	$101.25
	Mount, Horizontal, T1 51 0432 3mm (T1) 3-leaded LEDs w 3.0mm OD light pipe	$101.25
	Mount, Surface Mount 51 0410 Surface mount LEDs w/2.2mm OD light pipe	$68.63
	Mount, Surface Mount 51 0411 Surface mount LEDs w/3.0 mm OD light pipe	$70.88
Lens Caps	Description Part Number Application/Fiber Cable OD	Price (/PKG 500)
	Lens Cap, Light Pipe to Panel 51 0450 4.1mm diameter for 1mm thick panels w/ 2.2mm OD light pipe	$97.88
	Lens Cap, Light Pipe to Panel 51 0460 5mm diameter lens for 1mm thick panels w/ 2.2mm light pipe	$101.25
	Lens Cap, Light Pipe to Panel 51 0470 5mm diameter lens for 3mm panels w/ 2.2mm light pipe	$101.25
	Lens Cap, Light Pipe to Panel 51 0480 5mm diameter lens for 1mm thick panels w/ 3.0mm light pipes	$101.25
