Image Product Name
POF Transmissive Slot 1 mm core POF Transmissive Slot 1 mm core
U shaped sensing tip DC-1000, 2 +/- 0.05 m, 2 +/- 0.05 m
IF FPBU10U02AAN-02-0
Industrial Fiber Optics has introduced a U shaped slot sensor cable with a fiber cutter. It is used by either detecting an object passing through the slot which blocks the light or by having a solid material pass through the slot and detecting light passing through a gap in the material. The cable has a pair of 1 mm plastic optical core fibers with 2.2 mm polyethylene jackets. The sensor head is blue anodized aluminum with two 3.2 mm mounting holes. The standard length for each cable is 2 meters which can be trimmed to length with the included fiber cutter. Longer lengths, custom configurations and terminated control ends are available to meet customer requirements.
Fiber Optic Sensor Cables Fiber Optic Sensor Cables
IF FP1AA1U02AAN-02-0
IF FP1AA1U03AAN-02-0
IF FPBAA2U02AAN-02-0
IF FPBAA3U03AAN-02-0

Industrial Fiber Optics has introduced a line of POF sensor cables compatible with standard industrial photoelectric sensors. These new cables are available in transmissive and reflective (bifurcated) designs. Both 1 mm and 1.5 mm POF core sizes are available to meet customer sensing requirements. Custom cables can also be made with different fiber types and tip configurations. Contact us and our tech team will be happy to assist you with your custom design.
Low Smoke Zero Halogen 1 mm POF Patchcords Low Smoke Zero Halogen 1 mm POF Patchcords
IF 3118

Industrial Fiber Optics has expanded its line of POF patchcords with a new Low Smoke Zero Halogen (LSZH) cable. These new patchcords do not use halogenated flame retardands. This is in alignment with specifications such as Jedec JS709 and IEC 61249-2 which require a reduction in the use of brominated and chlorinated flame retardands. Patchcords are available with SMA, ST or Versalink connectors. Custom cables can also be made with this LSZH cable. Contact us and our tech team will be happy to assist you with your custom design.

Low Smoke Zero Halogen 200/230 um glass Patchcords Low Smoke Zero Halogen 200/230 um glass Patchcords
IF 5118

Industrial Fiber Optics has expanded its line of glass patchcords with a new Low Smoke Zero Halogen (LSZH) cable. These new patchcords do not use halogenated flame retardands. This is in alignment with specifications such as Jedec JS709 and IEC 61249-2 which require a reduction in the use of brominated and chlorinated flame retardands. Patchcords are UL riser rated and are available with SMA, ST or Versalink connectors. Custom cables can also be made with this LSZH cable. Contact us and our tech team will be happy to assist you with your custom design.
